Fabrication Shop Drawings and Fabrication Details Drawings for Structural Industries
7Solutions India is a young developing company specializing in the provision of high quality professional Fabrication Shop Drawings and Fabrication Details Drawings for Structural Industries and engineering industry. Our company’s skill and quality of work is of the highest standard. We have extensive experience working with clients in the USA, Australia, UK and Canada. We have professional structural engineers, designers and steel detailers with 10 years+ experience each, who works as part of your team to deliver your requirements, we do not compromise on quality and we fully manage the entire process for you, interacting with the entire supply chain.
Our detailed steel fabrication drawings provide you a precise picture of each steel element and connections between them with accurate dimensions. With minimal inputs steel detailers convert drawings, hand sketches and documents into cost effective fabrication shop drawings.
Get a FREE quotation: http://www.7solutionsindia.com/inquiry.php
Our structural steel fabrication drawings include:
- Structural Steel Detailing Drawings
- Structural Shop Drawings
- Structural Foundation Plan Drawings
- Structural Floor Framing Plans Drawings
- Roof framing/Ceiling framing plan
- Stair Handrail Detailing Services
- Steel Bar Joist drawings
- Structural Beam, Column, Slab, Frame Drawings
- Anchor Setting Plan
- Erection Drawings
- Structural Lintel Drawings
- Details of connections, anchorage, framing, etc.
Our steel fabrication detailing drawings for the following types of projects:
- Multi-story steel, concrete and masonry buildings
- One and two-story timber structures
- Pre-engineered structures
- Foundation structures for all types of building construction
- Light gauge metal structures
- Residential structures
Our mission is to help our customers meet their need for an aggressively compacted fabrication drawings project schedule without any increase in costs. We have undertaken the preparation of fabrication drawings for Power Plants, Cement Plants, Steel Plants , Industrial companies and Petrochemical Refineries. We will provide details drawings for Columns, beams, slabs, foundation, with Bar Bending schedule.
